PCMFXHDMI2BA-C Series
參數類型
| 型號 | Package version | Package name | Size (mm) | Configuration | Nr of lines | VRWM (V) (V) | Cd [typ] (pF) | IPPM [max] (A) | VESD (kV) (kV) |
|---|---|---|---|---|---|---|---|---|---|
| PCMF1HDMI2BA-C | OL-PCMF1HDMI2BA-C | WLCSP5 | 0.77 x 1.17 x 0.61 | Bidirectional | 1 | - | 0.3 | 7.5 | 15 |
| PCMF2HDMI2BA-C | OL-PCMF2HDMI2BA-C | WLCSP10 | 1.57 x 1.17 x 0.61 | Bidirectional | 2 | - | 0.3 | 7.5 | 15 |
| PCMF3HDMI2BA-C | OL-PCMF3HDMI2BA-C | WLCSP15 | 2.37 x 1.17 x 0.61 | Bidirectional | 3 | - | 0.3 | 7.5 | 15 |
封裝
| 型號 | 可訂購的器件編號，（訂購碼(12NC)） | 狀態 | 標示 | 封裝 | 外形圖 | 回流焊/波峰焊 | 包裝 |
|---|---|---|---|---|---|---|---|
| PCMF1HDMI2BA-C | PCMF1HDMI2BA-CZ (934661974087) |
Active |
WLCSP5 (OL-PCMF1HDMI2BA-C) |
OL-PCMF1HDMI2BA-C | 暫無信息 | ||
| PCMF2HDMI2BA-C | PCMF2HDMI2BA-CZ (934661975087) |
Active |
WLCSP10 (OL-PCMF2HDMI2BA-C) |
OL-PCMF2HDMI2BA-C | 暫無信息 | ||
| PCMF3HDMI2BA-C | PCMF3HDMI2BA-CZ (934661976087) |
Active |
WLCSP15 (OL-PCMF3HDMI2BA-C) |
OL-PCMF3HDMI2BA-C | 暫無信息 |
環境信息
| 型號 | 可訂購的器件編號 | 化學成分 | RoHS | RHF指示符 |
|---|---|---|---|---|
| PCMF1HDMI2BA-C | PCMF1HDMI2BA-CZ | PCMF1HDMI2BA-C |
|
|
| PCMF2HDMI2BA-C | PCMF2HDMI2BA-CZ | PCMF2HDMI2BA-C |
|
|
| PCMF3HDMI2BA-C | PCMF3HDMI2BA-CZ | PCMF3HDMI2BA-C |
|
|
文檔 (7)
| 文件名稱 | 標題 | 類型 | 日期 |
|---|---|---|---|
| PCMFXHDMI2BA_C_SER | Common-mode EMI filter for differential channels with integrated bidirectional ESD protection | Data sheet | 2020-05-20 |
| OL-PCMF2HDMI2BA-C | 3D model for products with OL-PCMF2HDMI2BA-C package | Design support | 2023-03-13 |
| OL-PCMF3HDMI2BA-C | 3D model for products with OL-PCMF3HDMI2BA-C package | Design support | 2023-03-13 |
| RS3303_WLCSP15 | RS3303_WLCSP15 | Marcom graphics | 2021-03-11 |
| OL-PCMF1HDMI2BA-C | wafer level chip-size package; 5 bumps (2-1-2) | Package information | 2023-05-31 |
| OL-PCMF2HDMI2BA-C | wafer level chip-size package; 10 bumps (4-2-4) | Package information | 2022-01-04 |
| OL-PCMF3HDMI2BA-C | wafer level chip-size package; 15 bumps (6-3-6) | Package information | 2022-01-04 |
支持
如果您需要設計/技術支持，請告知我們并填寫 應答表 我們會盡快回復您。
模型
| 文件名稱 | 標題 | 類型 | 日期 |
|---|---|---|---|
| OL-PCMF2HDMI2BA-C | 3D model for products with OL-PCMF2HDMI2BA-C package | Design support | 2023-03-13 |
| OL-PCMF3HDMI2BA-C | 3D model for products with OL-PCMF3HDMI2BA-C package | Design support | 2023-03-13 |
